SMX-200 VECOW

Document overview

  • Manufacturer or author: Provided By www.digicamel.com(FREE DATASHEET DOWNLOAD SITE)
  • PDF pages: 1

Technical content

Features

Unit : mm/ inchDimensions www.vecow.com SMX-200-20171107 * The rights of all brand names, product names and trademarks belong to their respective owners. Copyright © 2017 Vecow Co., Ltd. All rights reserved. 21.1 (0.8") 121.0 (4.8") 30.90 (1.2") 48.05 (1.9") 50.95 (2.0") 30.00 (1.2") 6.40 (0.3") 15.4 (0.6") 19.5 (0.8") 9.90 (0.4") 4-R2.50 Scale 2:1 Panel Cut-Out for DB9 24.20 (1.0") ƒ 4-port high-speed RS-232/422/485 ƒ Each serial channel supports up to 2.5kV Isolation ƒ Up to 31.25Mbps super fast data transmission ƒ -40°C to 85°C Operating Temperature ƒ PCI Express Mini Card 1.2 compliant, compact size ƒ Interrupt Status Register for Performance Enhancement SMX-200 Mini PCIe 4-port Isolated RS-232/422/485 Serial Card, -40°C to 85°C SMX-200 Mini PCIe 4-port Isolated RS-232/422/485 Serial Card Serial Interface Mini PCIe Controller EXAR XR17V354 Standard RS-232/422/485 (2.5kV Isolation) Number of Port 4 Baud Rate Up to 921.6kbps FIFOs 256 byte Flow Control CTS/RTS, Xon/Xoff Software Support OS Windows 10, Windows 8.1, Windows 7, Linux Mechanical Dimensions (W x L) Mini Card : 30mm x 51mm Cable Length : 260mm Weight 145 g Environment Operating Temperature -40°C to 85°C (-40°F to 185°F) Storage Temperature -40°C to 85°C (-40°F to 185°F) Humidity 5% to 95% Humidity, non-condensing Relative Humidity 95% @ 85°C EMC CE, FCC Packing List

1 SMX-200 Serial Card

2 Cable Set

1 Driver CD

1 Screw Kit

2 Bracket

-40º 85º
