MTC-4015-2R VECOW
Document overview
- Manufacturer or author: Provided By www.digicamel.com(FREE DATASHEET DOWNLOAD SITE)
- PDF pages: 2
Technical content
Features
Multi-Touch Computer/ Display www.vecow.com 15” 1024 x 768 (4 : 3) LCD Panel with LED Backlight Projected Capacitive Multi-Touch Screen with 7H Anti-Scratch Surface, up to 20-point Multi-touch Fanless, 5th Generation Intel Core™ i7/ i5/ i3 Processor (Broadwell-U) 6V to 36V DC-in, 80V Surge Protection 2 Independent Gigabit LAN 2 External SIM Socket support 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS External CFast Socket, 2 SSD Tray, 4 COM, 2 USB 3.0 16 DIO, Ignition Control Touchscreen works with gloves IP65 Front Panel Protection (Optional) MTC-4015-2R 15” Fanless Multi-Touch Computer, Intel Core™ i7/ i5/ i3 Processor (Broadwell-U) with 2 Gigabit LAN, 2 External SSD Tray,
2 External SIM Socket, 4 COM, 5 USB, 6V to 36V DC-in with 80V Surge Protection, Extended Temperature
2 Mini PCIe Socket :
1 Mini PCIe for PCIe/ USB/ SIM Card 1 Mini PCIe for PCIe/ USB/ SIM Card/ mSATA Storage SATA 2 SATA III (6Gbps) mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Storage Device 1 External CFast Socket 2 2.5" SSD/ HDD Tray (External) Power Power Input 6V to 36V, DC-in Power Interface 3-pin Terminal Block : V+, V-, Frame Ground Mini-DIN 4-pin Power Adapter AC to DC 120W Power Adapter (Optional) Ignition Control 16 Mode (Internal) Remote Switch 3-pin Terminal Block : On, Off, IGN Surge Protection Up to 80V/1ms Transient Power Others TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface Watchdog Timer Reset : 1 to 255 sec./min. per step Smart Management Wake on LAN, PXE supported HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats. Mechanical Dimensions (W x H x L) 350.0mm x 274.0mm x 97.6mm Weight 5.3 kg (11.7 lb) Front Panel Protection IP65 Compliant (Optional) Mounting VESA Mount (75 x 75mm, 100 x 100mm) Panel Mount Environment Operating Temperature -20°C to 70°C (-4°F to 158°F) Storage Temperature -30°C to 80°C (-22°F to 176°F) Humidity 10% to 90% Humidity, non-condensing Shock IEC 60068-2-27 20G, Half-sine, 11ms Vibration IEC 60068-2-64 Non-operation : 10Hz to 200Hz, 1.5Grms, X, Y, Z, 30 mins each Axis EMC CE, FCC Panel Panel Type TFT LCD Active Area 15" (4 : 3) Max. Resolution 1024 x 768 Display Color 16.7M (RGB 8-bit) Backlight LED Backlight Brightness (cd/m ) 250 Viewing Angle 160°/160° (H/V) Contrast Ratio 600 : 1 Touch Screen Touch Screen Type 20-point Projected Capacitive Transparency 91% Surface Hardness 7H Surface Hardness Control Interface USB Interface System Processor Intel Core™ i7-5650U/ i5-5350U/ i3-5010U Processor (Broadwell-U) Chipset Intel SoC Memory 2 DDR3L 1333/ 1600 MHz SO-DIMM, up to 16GB Graphics Intel HD Graphics 6000 Ethernet 1 Intel I218 Gigabit LAN 1 Intel I210 Gigabit LAN Audio Realtek ALC892, 5.1 Channel HD Audio OS Support Windows 8, Windows 7, Linux I/O Interface Serial 4 COM RS-232/ 422/ 485 USB 2 USB 3.0 3 USB 2.0 DIO 16 DIO : 8 DI, 8 DO LAN 2 Independent Gigabit LAN Audio 1 Mic-in, 1 Line-out Display DVI-D : Up to 1920 x 1080 @ 60Hz DisplayPort : Up to 3840 x 2160 @ 60Hz LED Power, HDD CFast 1 External CFast Socket, Push-in/ Push-out Ejector SIM Card 2 External SIM Card Socket 6V~36V 80V TPM SIM1080p Full HD IP65
Unit : mm/ inch Multi-Touch Computer/ Display www.vecow.com High Performance Embedded System Expandable Embedded System Ultra Compact Embedded System Multi-Touch Computer/ Display Frame Grabber 75,0 (3,0) 100,0 (3,9) 75,0 (3,0) 100,0 (3,9) 306,2 (12,1) 350,0 (13,8) 230,2 (9,1) 274,0 (10,8) 252,2 (9,9) 97,6 (3,8) MTC-4015-2R650U MTC-4015 15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel Core™ i7-5650U MTC-4015-2R350U MTC-4015 15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel Core™ i5-5350U MTC-4015-2R010U MTC-4015 15" Fanless Multi-Touch Computer, 2 GbE LAN, 2 SSD Tray, 2 SIM, 4 COM, 5 USB, Isolated DIO, Onboard Intel Core™ i3-5010U MTC-4015P MTC-4015 15" Fanless Multi-Touch Computer with 5th Gen Intel Core™ i7/ i5/ i3 Processor (Broadwell-U), built with IP65 Front Bezel DDR3L4G Certified DDR3L-1600 4G RAM DDR3L8G Certified DDR3L-1600 8G RAM PWA-120W 120W, 24V, 90VAC to 264VAC Power Adapter with 3-pin Terminal Block PWA-120WM4P 120W, 24V, 90VAC to 264VAC Power Adapter with 4-pin Mini-DIN Connector PWA-160W-WT 160W, 24V, 85VAC to 264VAC Power Adapter with 3-pin Terminal Block, Wide Temperature -30°C to +70°C Panel-Mount Panel Mount Kit VESA Stand VESA Table Stand 3G Module Mini PCIe 3G/GPS Module with Antenna 4G Module Mini PCIe 4G/GPS Module with Antenna WiFi & Bluetooth Module Intel Mini PCIe WiFi & Bluetooth Module with Antenna DVI-D 2 x USB 3.0 CFast 2 x USB 2.0 2 x LAN 2 x SIMDisplayPortLED Power 2 x SSD/HDD Tray Mic-in USB 2.0 DIO Remote Power Switch DC-in 4 x COM Line-out
